Your advantages:



? Integrated direct drive with DAC classic control incl. operating panel OP1000

? The large clearance (700 mm wide and 125 mm high) facilitates the handling of large-area workpieces

? Powerful and effective feeding system with bottom feed, needle feed and alternating top feed

? Up to 12 mm long stitches for standard seams and decorative topstitching

? The extremely high sewing foot lift up to 20 mm facilitates the feeding and removing of bulky workpieces

? The sewing foot stroke up to 9 mm allows the safe climbing over differently high material plies

? Thread sizes up to Nm 10/3 max.

? Asymmetrical sewing equipment for the twin-needle machines allows the flexible use as single-needle or twin-needle version by conversion





Typical field of application

Assembly and decorative seams in large-area workpieces



Performance features

? Max. stitch length 12 mm

? Max. sewing speed 3,000 stitches/min.
